PAD50-3
SYX MOTO Holeshot ES 50cc Electric Start/Pull Start Mini Dirt Bike
Gas Powered 2-Stroke Off Road Pit Bike Fully Automatic Transmission
Taxes and shipping calculated at checkout
Couldn't load pickup availability
💯 100% Satisfaction Guaranteed
- WHAT'S IN THE BOX - SYX MOTO Holeshot ES Mini Dirt Bike. Tool kit and hardware required to assemble the unit. Owner's Manual. Decal set.
- EASY TO INSTALL: 85% assembled, all you need to do is the install the rear shock absorber, front wheel, handlebar and the fender and then HERE YOU GO! Created with high quality material for handling all types of tough situations. Recommended age of rider is 6 years old and up.
- WARRANTY COVERED: We warranty the products to be free of material defects in workmanship for the warranty period from the date your product is delivered. Damages on Arrival shall be notified WITHIN 3 BUSINESS DAY UPON DELIVERED. Engine is covered to be free from manufacturer defect for three (3) month. Parts are covered under warranty to be free from manufacturer defects for one (1) month. Warranty details is attached below in the description.
- 365-DAY CUSTOMER SERVICE: We provide 365-day customer service via email support during working days.
Share
More Information
Shipping
Specifications
| Engine | |
| Engine Type | 2 Stroke, Single Cylinder |
| Displacement | 50cc |
| Bore and Stroke | 1.73 inches x 1.31 inches |
| Starter | Electric Start & Pull Start |
| Cooling | Air Cooled |
| Max Speed | 30 mph May vary depending on road condition, rider weight etc. |
| Compression Ratio | 8.0:1 |
| Rated Power | 2.52HP/7000rpm |
| Carburetor | H117A FLOAT (PLUNGER) |
| Fuel grade | 91# gas |
| Mixture ratio of fuel & lubricant oil | 20~25:1 |
| Drive Train | |
| Transmission | Automatic Centrifugal |
| Drive System | Chain |
| Chassis / Suspension / Brakes | |
| Wheel Type | Alloy |
| Rear Suspension | Spring |
| Front Brake | Disc |
| Rear Brake | Disc |
| Front Tire | 2.5-10 |
| Rear Tire | 2.5-10 |
| Dimensions / Capacities | |
| Length | 50.4 inches |
| Width | 22 inches |
| Height | 33.5 inches |
| Seat Height | 21 inches |
| Ground Clearance | 7.5 inches |
| Net Weight | 48 lbs |
| Gross Weight | 57 lbs |
| Weight Capacity | 176 lbs |
| Fuel Capacity | 0.45 gal |
| Other | |
| Restrictions | CA Legal with Red Sticker |
Owner's Manual Download
Click to download: PAD50-3 Owner's Manual
Warranty Policy
Model No.
PAD50-3
Details
Customer Photos
Assembly Guide
QUESTIONS & ANSWERS
Ask a Question-
What\'s the shipping fee?
It starts from $30, which depends on the item weight, delivery location and shipping method you choose. Fees will be calculated automatically at checkout.
-
How to assemble it?
Please refer to our YouTube video. Link: https://www.youtube.com/watch?v=5SBMPtEB8uI
-
Can you ship to California?
Yes, this model can be shipped to California.
-
The description says this is electric start, however the pictures show and state pull start. Which is it?
Hi, Holeshot ES is with both electric start and pull start.
-
Is this automatic or does it have to be shifted?
It is automatic.
-
how long does the fuel last until it run out of fuel
Around 50km.
-
Coil on the spark plug wire(one complete unit) single plug.. Replacement part needed.. What is the reference number or part name? Thank you
The part name is Ignition Coil and you can order it by the following link:
https://syxmoto.com/products/syx-moto-spark-plug-ignition-coil-parts-replacement?_pos=1&_sid=a6f396a55&_ss=r&variant=39501880590422 -
What size chain is on this bike? Mine is all rusted and brittle!!
The size is T8F*134
